| Performance and Characteristics : |
| This machine can produce pe and cpe sleeve, with good quality and low price, yield advantages, save labor, reduce costs, can be made according to customer requirements, this machine is automated. Products from raw materials to products sent to the layer count full automation. Ultra high-power ultrasonic welding, the two ends of the sleeve and the effective elastic constant. Into the entire process from raw materials to finished products for automation, industry, only one person throughout the operation. |
| |
| Production Process : |
| Automatic feed - import - folding - welding - forming cut Self-developed version of the latest automatic manufacturing equipment cuff can produce various specifications of pe, cpe cuff, elastic band to adapt to produce products, business opportunities currently on the market. |
| |
| Machine Features : |
- Frequency control.
- Material output to be a finished product.
- Automatic temperature control.
- High-power ultrasonic welding combined with the electric co.
|
| Technical Parameters : |
| Output |
100-150 PCS/MIN |
| Voltage |
220V 60HZ |
| Power |
4.5KW |
| Weight |
600KG |
| Dimension |
2400MM*1200MM*1100MM(L*H*W) |
|
| |
| Products Images : |
|
| |
| Spare Parts Lists : |
| Item |
Quantity |
| Knife Blade |
2 PIECES |
| Electronic Tape |
1 PIECE |
| Belt |
1 PIECE |
| Tungsten Wire |
1 METER |
| Adjustable Wrench |
1 SET |
| Allen Wrench |
1 SET |
| Screwdriver |
1 PIECE |
| Instruction |
1 |
| Welding Gear |
1 PIECE |
|
| |
| Sleeve Cover Materials Report : |
| Item Name |
Plastic Film |
Rubber |
Nonwoven |
| PHOTO |
 |
 |
 |
| Specification |
60%-70%(hdpe) + 30%-40% (ldpe) materials Thickness :10 micron-12 micron |
Diameter :1 MM |
WIDTH :2 CM THICKNESS:30 G |
|
| Remarks : |
| You maybe doubt why the plastic sleeve cover need the nonwoven(spun bond).actually ,the nonwoven function is to fix the rubber in the sleeve cover .please check the photo as fellow: |
 |
